C08-AG HI TIP+ Yanmar C08-AG HI TIP+ Specifications & Technical Data (2023—2026)

Weight: 0.74t – Transport length: 2.595m – Transport width: 0.835m – Transport height: 1.35m – Net load: 0.8t – Dump capacity: 0.34m³

C08-AG HI TIP+

Years of manufacture: 2023—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - C08-AG HI TIP+ Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 0.74 t

Transport length: 2.595 m

Transport width: 0.835 m

Transport height: 1.35 m

Net load: 0.8 t

Dump capacity: 0.34 m³

Travel speed: 4 km/h

Track width: 180 mm

Soil pressure: 0.56 kg/cm²

Loading height: 0.739 m

Model series: C

Engine manuf.: Kohler

Engine type: CH440

Engine power: 9.9 kW

Displacement: 0.435 l

Max. torque: 24,3/3100 Nm

More technical details, like: driver protection, turning radius outside, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: Yes
Heated dump body: No
Electric starter: Yes
Trough liftable: Yes
Aircondition: No

Download datasheets (PDF)

Yanmar C08-AG HI TIP+ FAQ

When was the Yanmar C08-AG HI TIP+ manufactured?

The Yanmar C08-AG HI TIP+ was first produced in 2024.

How much does the Yanmar C08-AG HI TIP+ weigh?

The Yanmar C08-AG HI TIP+ weighs 0.74 tons.

What are the transport dimensions of the Yanmar C08-AG HI TIP+ tracked dumper?

The Yanmar C08-AG HI TIP+ has a transport length of 2.595 meters, a transport width of 0.835 meters, and a transport height of 1.35 meters.

What is the travel speed of the Yanmar C08-AG HI TIP+ tracked dumper?

The Yanmar C08-AG HI TIP+ has a travel speed of 4 km/h.

What are the undercarriage specifications of the Yanmar C08-AG HI TIP+?

The Yanmar C08-AG HI TIP+ has a track width of 180 mm and a soil pressure of 0.56 kg/cmu00b2.

What is the material handling capacity of the Yanmar C08-AG HI TIP+ tracked dumper?

The Yanmar C08-AG HI TIP+ tracked dumper has a net load capacity of 0.8 tons, a dump capacity of 0.34 cubic meters, and a loading height of 0.739 meters.

How much is a Yanmar C08-AG HI TIP+ Tracked dumper (2024u20132025) worth?

The residual value of the Yanmar C08-AG HI TIP+ depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
