Technical specs - DT10 Wacker Neuson
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 0.7 t
- Transport length
- 1.82 m
- Transport width
- 0.79 m
- Transport height
- 1.45 m
- Net load
- 1 t
- Dump capacity
- 0.393 m³
- Travel speed
- 4 km/h
- Soil pressure
- 0.52 kg/cm²
- Model series
- DT
- Engine manuf.
- Kubota
- Engine type
- Z482E
- Engine power
- 9.6 kW
- Displacement
- 0.479 l
- Revolutions at max torque
- 3600 rpm
More technical details, like: driver protection, track width, loading height, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Track adjustment
-
No
- Bucket
-
No
- Heated dump body
-
No
- Electric starter
-
No
- Trough liftable
-
No
- Aircondition
-
No
Download datasheets (PDF)
