MST 300 VD Morooka MST 300 VD Specifications & Technical Data (1999—2013)

Weight: 2.2t – Transport length: 3.16m – Transport width: 1.64m – Transport height: 1.62m – Net load: 2.5t – Dump capacity: 0.88m³

MST 300 VD

Years of manufacture: 1999—2013

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - MST 300 VD Morooka

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.2 t

Transport length: 3.16 m

Transport width: 1.64 m

Transport height: 1.62 m

Net load: 2.5 t

Dump capacity: 0.88 m³

Driver protection: Kb

Travel speed: 9 km/h

Track width: 350 mm

Soil pressure: 0.16 kg/cm²

Loading height: 1.195 m

Turning radius outside: 1.6 m

Model series: MST

Engine manuf.: Kubota

Engine type: V2203B

Engine power: 34 kW

Displacement: 2.197 l

Revolutions at max torque: 2800 rpm

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: Yes
Trough liftable: Yes
Aircondition: No

Download datasheets (PDF)

Morooka MST 300 VD FAQ

When was the Morooka MST 300 VD manufactured?

The Morooka MST 300 VD was manufactured from 1999 to 2013.

How much does the Morooka MST 300 VD weigh?

The Morooka MST 300 VD weighs 2.2 tons.

What are the transport dimensions of the Morooka MST 300 VD?

The Morooka MST 300 VD has a transport length of 3.16 meters, a transport width of 1.64 meters, and a transport height of 1.62 meters.

What is the travel speed of the Morooka MST 300 VD?

The Morooka MST 300 VD has a travel speed of 9 km/h.

What are the undercarriage specifications of the Morooka MST 300 VD?

The Morooka MST 300 VD has a track width of 350 mm and a soil pressure of 0.16 kg/cmu00b2.

What is the turning radius of the Morooka MST 300 VD tracked dumper?

The Morooka MST 300 VD has an outside turning radius of 1.6 meters.

What is the material handling capacity of the Morooka MST 300 VD?

The Morooka MST 300 VD has a net load capacity of 2.5 tons, a dump capacity of 0.88 cubic meters, and a loading height of 1.2 meters.

What operator safety feature does the Morooka MST 300 VD have?

The Morooka MST 300 VD has a driver protection cabin.

How much is a Morooka MST 300 VD Tracked dumper (1999u20132013) worth?

The residual value of the Morooka MST 300 VD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
