MST 2200 VD Morooka MST 2200 VD Specifications & Technical Data (2016—2021)

Weight: 14.1t – Transport length: 6.26m – Transport width: 2.85m – Transport height: 3.8m – Net load: 11t – Dump capacity: 3.53m³

MST 2200 VD

Years of manufacture: 2016—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - MST 2200 VD Morooka

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 14.1 t

Transport length: 6.26 m

Transport width: 2.85 m

Transport height: 3.8 m

Net load: 11 t

Dump capacity: 3.53 m³

Driver protection: Kb

Travel speed: 10 km/h

Track width: 750 mm

Soil pressure: 0.41 kg/cm²

Loading height: 1.83 m

Turning radius outside: 3.5 m

Model series: MST

Engine manuf.: Cummins

Engine type: QSB6.7

Engine power: 186 kW

Revolutions at max torque: 2200 rpm

Max. torque: 990/1500 Nm

Emission level: Tier 4 f

More technical details, like: dimension lxwxh, displacement, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: No
Trough liftable: No
Aircondition: Yes

Download datasheets (PDF)

MST 2200 VD Morooka Specification for Europe (EN)

Morooka MST 2200 VD FAQ

When was the Morooka MST 2200 VD manufactured?

The Morooka MST 2200 VD was manufactured from 2016 to 2021.

How much does the Morooka MST 2200 VD weigh?

The Morooka MST 2200 VD weighs 14.1 tons.

What are the transport dimensions of the Morooka MST 2200 VD?

The Morooka MST 2200 VD has a transport length of 6.26 meters, a transport width of 2.85 meters, and a transport height of 3.8 meters.

What is the travel speed of the Morooka MST 2200 VD?

The Morooka MST 2200 VD has a travel speed of 10 km/h.

What are the undercarriage specifications of the Morooka MST 2200 VD?

The Morooka MST 2200 VD has a track width of 750 mm and a soil pressure of 0.41 kg/cmu00b2.

What is the turning radius of the Morooka MST 2200 VD tracked dumper?

The Morooka MST 2200 VD has an outside turning radius of 3.5 meters.

What is the material handling capacity of the Morooka MST 2200 VD tracked dumper?

The Morooka MST 2200 VD has a net load capacity of 11 tons, a dump capacity of 3.53 cubic meters, and a loading height of 1.83 meters.

What operator safety and support features does the Morooka MST 2200 VD have?

The Morooka MST 2200 VD provides operator safety with a driver protection cabin.

How much is a Morooka MST 2200 VD Tracked dumper (2016u20132021) worth?

The residual value of the Morooka MST 2200 VD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
