TX3005 Hinowa TX3005 Specifications & Technical Data (2021—2026)

Weight: 2.5t – Transport length: 3.599m – Transport width: 1.55m – Transport height: 2.382m – Net load: 2.875t – Dump capacity: 1.49m³

TX3005

Years of manufacture: 2021—2026

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - TX3005 Hinowa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.5 t

Transport length: 3.599 m

Transport width: 1.55 m

Transport height: 2.382 m

Net load: 2.875 t

Dump capacity: 1.49 m³

Driver protection: FD

Travel speed: 11 km/h

Track width: 320 mm

Model series: TX

Engine manuf.: Kubota

Engine type: V2403

Engine power: 37.4 kW

Displacement: 2.197 l

Revolutions at max torque: 2700 rpm

No. of cylinders: 4

Emission level: V

More technical details, like: soil pressure, loading height, turning radius outside, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: Yes
Trough liftable: No
Aircondition: No

Download datasheets (PDF)

Hinowa TX3005 FAQ

When was the Hinowa TX3005 manufactured?

The Hinowa TX3005 was first produced in 2021.

How much does the Hinowa TX3005 weigh?

The Hinowa TX3005 weighs 2.5 tons.

What are the transport dimensions of the Hinowa TX3005?

The Hinowa TX3005 has a transport length of 3.6 meters, a transport width of 1.55 meters, and a transport height of 2.38 meters.

What is the travel speed of the Hinowa TX3005 tracked dumper?

The Hinowa TX3005 has a travel speed of 11 km/h.

What is the track width of the Hinowa TX3005's undercarriage?

The Hinowa TX3005 has a track width of 320 mm.

What is the material handling capacity of the Hinowa TX3005 tracked dumper?

The Hinowa TX3005 tracked dumper has a net load capacity of 2.88 tons and a dump capacity of 1.49 cubic meters.

What operator safety and support features does the Hinowa TX3005 have?

The Hinowa TX3005 is equipped with a canopy for driver protection.

How much is a Hinowa TX3005 Tracked dumper (2021u20132025) worth?

The residual value of the Hinowa TX3005 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
