Hinowa HS1103 Specifications & Technical Data (2014-2026)

Technical specs - HS1103 Hinowa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 0.97 t

Transport length: 2.33 m

Transport width: 0.75 m

Transport height: 1.47 m

Net load: 1 t

Dump capacity: 0.52 m³

Travel speed: 5 km/h

Track width: 230 mm

Model series: HS

Engine manuf.: Kubota

Engine type: D722

Engine power: 15 kW

Displacement: 0.72 l

Revolutions at max torque: 3600 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: driver protection, soil pressure, loading height, turning radius outside, dimension lxwxh, max. torque, cylinder bore x stroke, model type, driveline, rops, fops, engine manufacturer...

More technical details, like: driver protection, soil pressure, loading height, turning radius outside, dimension lxwxh, max. torque, cylinder bore x stroke, model type, driveline, rops, fops, engine manufacturer, engine model, rated speed, engine output, fuel, drive, track rollers - each side, track shoe width, width, overall length, skip lip height - tipped, payload - heaped, payload - struck, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: Yes
Trough liftable: No
Aircondition: No

Download datasheets (PDF)

Hinowa HS1103 FAQ

When was the Hinowa HS1103 manufactured?

The Hinowa HS1103 was first produced in 2014.

What is the weight of the Hinowa HS1103 tracked dumper?

The Hinowa HS1103 tracked dumper weighs 0.97 tons.

What are the transport dimensions of the Hinowa HS1103 tracked dumper?

The Hinowa HS1103 has a transport length of 2.33 meters, a transport width of 0.75 meters, and a transport height of 1.47 meters.

What is the travel speed of the Hinowa HS1103 tracked dumper?

The travel speed of the Hinowa HS1103 tracked dumper is 5 km/h.

What is the track width of the Hinowa HS1103 tracked dumper?

The Hinowa HS1103 tracked dumper has a track width of 230 mm.

What is the material handling capacity of the Hinowa HS1103 tracked dumper?

The Hinowa HS1103 tracked dumper has a net load capacity of 1 ton and a dump capacity of 0.52 cubic meters.

How much is a Hinowa HS1103 Tracked dumper (2014u20132025) worth?

The residual value of the Hinowa HS1103 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
