Hinowa HS1100B Specifications & Technical Data (2006-2015)

Technical specs - HS1100B Hinowa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 0.57 t

Transport length: 1.82 m

Transport width: 0.758 m

Transport height: 1.875 m

Net load: 1.1 t

Dump capacity: 0.4 m³

Travel speed: 4 km/h

Track width: 180 mm

Model series: HS

Engine manuf.: Honda

Engine type: GX390

Engine power: 9.5 kW

Displacement: 0.39 l

Revolutions at max torque: 3600 rpm

More technical details, like: driver protection, soil pressure, loading height, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, rops...

More technical details, like: driver protection, soil pressure, loading height, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, rops, fops, engine manufacturer, engine model, rated speed, engine output, fuel, drive, track shoe width, width, overall length, skip lip height - untipped, skip lip height - tipped, payload - heaped, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: Yes
Bucket: Yes
Heated dump body: No
Electric starter: Yes
Trough liftable: Yes
Aircondition: No

Download datasheets (PDF)

Hinowa HS1100B FAQ

When was the Hinowa HS1100B manufactured?

The Hinowa HS1100B was manufactured from 2006 to 2015.

How much does the Hinowa HS1100B tracked dumper weigh?

The Hinowa HS1100B tracked dumper weighs 0.57 tons.

What are the transport dimensions of the Hinowa HS1100B?

The Hinowa HS1100B has a transport length of 1.82 meters, a transport width of 0.76 meters, and a transport height of 1.88 meters.

What is the travel speed of the Hinowa HS1100B tracked dumper?

The Hinowa HS1100B has a travel speed of 4 km/h.

What is the track width of the Hinowa HS1100B's undercarriage?

The Hinowa HS1100B has a track width of 180 mm.

What is the material handling capacity of the Hinowa HS1100B tracked dumper?

The Hinowa HS1100B tracked dumper has a net load capacity of 1.1 tons and a dump capacity of 0.4 cubic meters.
