RD 6/5,5 B HX Gehlmax RD 6/5,5 B HX Specifications & Technical Data (2007—2012)

Weight: 0.39t – Transport length: 1.19m – Transport width: 0.61m – Transport height: 0.387m – Net load: 0.4t – Dump capacity: 0.29m³

RD 6/5,5 B HX

Years of manufacture: 2007—2012

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - RD 6/5,5 B HX Gehlmax

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 0.39 t

Transport length: 1.19 m

Transport width: 0.61 m

Transport height: 0.387 m

Net load: 0.4 t

Dump capacity: 0.29 m³

Track width: 180 mm

Model series: RD

Engine manuf.: Honda

Engine type: GX160

Engine power: 4 kW

Displacement: 0.163 l

Revolutions at max torque: 3600 rpm

No. of cylinders: 1

More technical details, like: driver protection, travel speed, soil pressure, loading height, turning radius outside, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: No
Trough liftable: No
Aircondition: No

Gehlmax RD 6/5,5 B HX FAQ

When was the Gehlmax RD 6/5,5 B HX manufactured?

The Gehlmax RD 6/5,5 B HX was manufactured from 2007 to 2012.

How much does the Gehlmax RD 6/5,5 B HX weigh?

The Gehlmax RD 6/5,5 B HX weighs 0.39 tons.

What are the transport dimensions of the Gehlmax RD 6/5,5 B HX tracked dumper?

The Gehlmax RD 6/5,5 B HX has a transport length of 1.19 meters, a transport width of 0.61 meters, and a transport height of 0.39 meters.

What is the track width of the Gehlmax RD 6/5,5 B HX's undercarriage?

The Gehlmax RD 6/5,5 B HX has a track width of 180 mm.

What is the material handling capacity of the Gehlmax RD 6/5,5 B HX tracked dumper?

The Gehlmax RD 6/5,5 B HX tracked dumper has a net load capacity of 0.4 tons and a dump capacity of 0.29 cubic meters.
