Technical specs - TP 580 Camisa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 0.34 t

Transport length: 2 m

Transport width: 0.7 m

Transport height: 1.07 m

Net load: 0.6 t

Dump capacity: 0.2 m³

Travel speed: 5 km/h

Engine manuf.: Lombardini

Engine type: LGA 340

Engine power: 7.4 kW

Displacement: 0.338 l

More technical details, like: driver protection, track width, soil pressure, loading height, turning radius outside, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: No
Trough liftable: No
Aircondition: No

Download datasheets (PDF)

Camisa TP 580 FAQ

When was the Camisa TP 580 manufactured?

The Camisa TP 580 was manufactured from 2003 to 2011.

How much does the Camisa TP 580 weigh?

The Camisa TP 580 weighs 0.34 tons.

What are the transport dimensions of the Camisa TP 580 tracked dumper?

The Camisa TP 580 has transport dimensions of 2 meters in length, 0.7 meters in width, and 1.07 meters in height.

What is the travel speed of the Camisa TP 580 tracked dumper?

The Camisa TP 580 tracked dumper has a travel speed of 5 km/h.

What is the material handling capacity of the Camisa TP 580 tracked dumper?

The Camisa TP 580 tracked dumper has a net load capacity of 0.6 tons and a dump capacity of 0.2 cubic meters.

How much is a Camisa TP 580 Tracked dumper (2003u20132011) worth?

The residual value of the Camisa TP 580 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
