Volvo PF3172 Specifications & Technical Data (2008-2012)

Technical specs - PF3172 Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 11.508 t

Transport length: 5.72 m

Transport width: 3.05 m

Transport height: 3.15 m

Standard width: 3.05 m

Max. width: 6.4 m

Hydr. extension from: 3 m

Hydr. extension up to: 6.4 m

Drive: DE

Bunker capacity: 5.15 m³

Operating speed: 69.2 m/min

Type of screed: V/T

More technical details, like: soil pressure, model series, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Vibration: Yes
High compaction: No
Spray unit: No
Tamper: Yes

Download datasheets (PDF)

PF3172 Volvo Specification for North America (EN)

Volvo PF3172 FAQ

When was the Volvo PF3172 manufactured?

The Volvo PF3172 was manufactured from 2008 to 2012.

How much does the Volvo PF3172 weigh?

The Volvo PF3172 weighs 11.51 tons.

What are the transport dimensions of the Volvo PF3172 tracked asphalt paver?

The Volvo PF3172 has a transport length of 5.72 meters, a transport width of 3.05 meters, and a transport height of 3.15 meters.

What is the operating speed of the Volvo PF3172 tracked asphalt paver?

The Volvo PF3172 has an operating speed of 69.2 meters per minute.

What type of undercarriage drive system does the Volvo PF3172 have?

The Volvo PF3172 has a diesel electric undercarriage drive system.

What are the paving performance specifications of the Volvo PF3172 tracked asphalt paver?

The Volvo PF3172 features a tamper and vibratory screed, a standard paving width of 3.05 meters, hydraulic extension from 3 meters up to 6.4 meters, an operating speed of 69.2 meters per minute, and a bunker capacity of 5.15 cubic meters.

How much is a Volvo PF3172 Tracked Asphalt Paver (2008u20132012) worth?

The residual value of the Volvo PF3172 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Volvo PF3172 overview

Crawler Units

Performance Features

Exclusive low-pressure tires provide larger 'footprint' for better flotation and tractionExclusive offset bogie front suspension distributes front-end weight more evenly for better tractionExclusive clamp-in conveyor floor plates reduces maintenance time compared to traditional bolt-in designsMaintenance-free sealed auger and conveyor bearings eliminate daily greasingHigh-efficiency 405.4 mm (16") augers are 19 mm (0.75") thick for better delivery and longer wearPatented power-adjustable auger height of 114.3 mm – 279.4 mm (4.5" – 11") lets the operator adjust quickly to varying job requirementsDual operator consoles enable operators to work safely with the best visibilityPinned engine hoods and removable deck plates provide convenient access to vital componentsEasy-access fillers and common-platform electrical systems reduce maintenance time.

Pavers

Achieve Perfect Placement on a Variety of Materials

Volvo Construction Equipment offers the Blaw-Knox PF2181 and PF3172, two high-capacity, wheel-mounted pavers built to place a variety of materials: bituminous base, binder, and surface course mixes; graded aggregate materials; and cement- or lime-stabilized sub-base. Both pavers are packed with high-performance features and plenty of options, all to reduce maintenance time, lower costs, and boost productivity.
