Terex CR562S Specifications & Technical Data (2008-2023)

Technical specs - CR562S Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 17.527 t

Transport length: 6.096 m

Transport width: 3.15 m

Transport height: 2.794 m

Standard width: 3.05 m

Max. width: 9.1 m

Drive: DE

Bunker capacity: 7.56 m³

Operating speed: 41 m/min

Type of screed: V

Engine manuf.: Cummins

Engine type: QSB6.7

Engine power: 194 kW

Revolutions at max torque: 2200 rpm

More technical details, like: hydr. extension from, hydr. extension up to, soil pressure, model series, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Vibration: No
High compaction: No
Spray unit: No
Tamper: No

Download datasheets (PDF)

CR562S Terex Specification for North America (EN)

Terex CR562S FAQ

When was the Terex CR562S manufactured?

The Terex CR562S was manufactured from 2008 to 2023.

How much does the Terex CR562S weigh?

The Terex CR562S weighs 17.53 tons.

What are the transport dimensions of the Terex CR562S?

The Terex CR562S has a transport length of 6.1 meters, a transport width of 3.15 meters, and a transport height of 2.79 meters.

What is the operating speed of the Terex CR562S tracked asphalt paver?

The Terex CR562S has an operating speed of 41 meters per minute.

What type of drive system does the Terex CR562S tracked asphalt paver use?

The Terex CR562S uses a diesel electric drive system for its undercarriage.

What are the paving performance specifications of the Terex CR562S asphalt paver?

The Terex CR562S features a vibratory screed, a standard paving width of 3.05 meters, a maximum paving width of 9.1 meters, and an operating speed of 41 meters per minute.

How much is a Terex CR562S Tracked Asphalt Paver (2008u20132023) worth?

The residual value of the Terex CR562S depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
