Marini MF 221 C Specifications & Technical Data (2003-2007)

Technical specs - MF 221 C Marini

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.63 t

Transport length: 4.27 m

Transport width: 1.4 m

Transport height: 2.25 m

Standard width: 1.4 m

Max. width: 3.2 m

Hydr. extension from: 1.4 m

Hydr. extension up to: 2.6 m

Drive: DH

Model series: MF

Engine manuf.: Perkins

Engine type: 403-15

Engine power: 21.5 kW

More technical details, like: soil pressure, bunker capacity, operating speed, type of screed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Vibration: Yes
High compaction: No
Spray unit: No
Tamper: No

Marini MF 221 C FAQ

When was the Marini MF 221 C manufactured?

The Marini MF 221 C was manufactured from 2003 to 2007.

How much does the Marini MF 221 C weigh?

The Marini MF 221 C weighs 4.63 tons.

What are the transport dimensions of the Marini MF 221 C?

The Marini MF 221 C has a transport length of 4.27 meters, a transport width of 1.4 meters, and a transport height of 2.25 meters.

What type of drive system does the Marini MF 221 C use in its undercarriage?

The Marini MF 221 C uses a diesel hydraulic drive system in its undercarriage.

What are the paving width capabilities of the Marini MF 221 C asphalt paver?

The Marini MF 221 C has a standard paving width of 1.4 meters, a maximum paving width of 3.2 meters, and a hydraulic extension range from 1.4 meters up to 2.6 meters.

How much is a Marini MF 221 C Tracked Asphalt Paver (2003u20132007) worth?

The residual value of the Marini MF 221 C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
