VMD 80 JCB-Vibromax VMD 80 Specifications & Technical Data (2008—2011)

VMF Series Vibratory Plate Compactors

The VMF Series has been specifically designed for easy, effective compaction of asphalt, granular soil and other non-cohesive (or less-cohesive) materials. Built for fast travel and high productivity, these machines feature a powerful petrol engine (diesel on the VMF 1300 D) and a water-resistant, high-grade cast tamping plate for optimum durability. There are four models to choose from to suit a wide range of compaction jobs.

VMP Series Reversible Plate Compactors

This comprehensive range of Plate Compactors provides a choice of models to suit every type of compaction application. All of the units are hydrostatically operated and designed to effectively compact granular soil and cohesive material. With a reversing and stationary feature, these machines allow you to carry out compaction tasks in confined areas where turning would be difficult (or impossible) for a non-reversing unit. All of the VMP models also feature high compaction output and surface performance for the toughest jobs.

VMD Series Double Drum Vibratory Rollers

Designed for low maintenance, high productivity and ease of service. Every VMD model features a water sprinkling system for asphalt compaction, but they are also ideal on granular materials, and non-cohesive and cohesive soils. The water tank on these models is made from stainless material (V2A) to prevent rust and guarantee maximum use and stability, while the exciter shaft bearings are lifetime oil splash lubricated for added durability.

Multi Purpose Vibratory Compactor

The JCB Vibromax VM1500 high-impact roller is the best performer of its type in the industry and, as you would expect, it is designed for maximum productivity on a variety of different soils. There are two models available: the manually controlled VM1500 M and the remote controlled VM1500 F. Both feature 4-drum drive and steering to allow operation in confined areas where turning would otherwise be extremely difficult, if not impossible.

VMT Series Vibratory Tandem Rollers

To ensure maximum quality, all machines in the JCB Vibromax VMT series are put through their paces on a test bench during a two-hour test run at the factory. The range of models features Vibratory Tandem Rollers designed to offer high productivity and reliability with maximum operating economy. The ideal combination of static weights, centrifugal forces and amplitudes makes these machines perfect for handling a wide range of compaction jobs (from the rolling of sub-base to finish rolling of asphalt materials) in a wide range of areas (yards, access roads, residential streets, car parks, roads, highways and airports) on soil and asphalt. All models boast excellent manoeuvrability, compact designs and many extra-values, as well as being available as combination versions with rubber tyres at the front or rear.

VM Series Vibratory Single Drum Compactors

To ensure maximum quality, all the machines in the JCB Vibromax VM Series are put through their paces on a test bench during a two-hour test run at the factory, so this is performance you know you can count on. The range of models features self-propelled vibratory rollers designed to offer high productivity and reliability with maximum operating economy. But these are also extremely versatile machines; two frequencies and amplitudes (except VM46) meet natural soil frequencies making them ideal for a wide range of cohesive soil jobs as well as compaction jobs on streets, roads, parking areas, building sites, rock-fill dams, super highways and airport projects. All VM models can handle thick lifts of cohesive soil jobs and superior gradeability is achieved through high-torque propulsion components, maximum balance of drum-to-tractor weight and a built-in anti-slip system.

Tow-Type Vibratory Compactors

The JCB Vibromax VM501 and VM651 are high-performance, low-cost Tow-Type Rollers designed for larger compaction sites where compaction needs to be done in intervals. The exciter shaft on these machines is hydraulically driven, vibration can be switched on and off from the towing vehicle, plus there is an electrical starting system and an optimal weight balance.

Asphalt Cutter

The JCB Vibromax TCC6 is an all-purpose machine perfect for cutting jobs on asphalt, concrete or any similar material. The cutting depth is easy to adjust with a spindle-operated wheel and a scale that shows you the exact depth measurement. The machine frame is built for strength and features a large integrated water tank that delivers sufficient water to keep the cutting blade cool. Additionally, there is a powerful air-cooled diesel engine, which makes operating this cutter smooth and easy.

VMR Series Rapid Blow Tampers

The JCB Vibromax VMR Series features a low-maintenance design that results in longer working hours for higher productivity. Strong and sturdy, these Tampers have a low centre of gravity with a four-column guide for a stable function, guaranteeing high reliability for continuous, fault-free working. Plus, these machines also generate a horizontal force for moving forwards which makes them easier for the operator to handle.

Rubber Tyred Roller

The VM2400 is designed for large compaction jobs of asphalt mixtures but can also be used for compacting non-cohesive and semi-cohesive soil. The machine features a backbone frame, eight smooth tyres, a rear axle that is driven through a hydrodynamic drive and a three-speed shiftable gearbox with gears that can be shifted under load. Plus, thanks to the isostatic suspension, the front wheels can adapt themselves to suit uneven terrain. It all helps make the VM2400 the professional solution for highway jobs and roads.
