BW 90 AD-5 Bomag BW 90 AD-5 Specifications & Technical Data (2011—2018)
.jpg)
.jpg)
.jpg)
.jpg)
Visit Bomag live at
Technical specs - BW 90 AD-5 Bomag
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.5 t
- Transport length
- 2.194 m
- Transport width
- 0.956 m
- Transport height
- 2.304 m
- Vibration
- d
- Drive
- A
- Steering
- KL
- Travel speed
- 10 km/h
- Frequency
- 63 Hz
- Roller width
- 0.9 m
- Rollers Ø
- 0.58 m
- Turning radius outside
- 2.03 m
- Statical line load
- 8.9 kg/cm
- Centrifugal force
- 17 kN
- Model series
- BW
- Engine manuf.
- Kubota
- Engine type
- D902
- Engine power
- 15.2 kW
More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
