Ammann ARX 36-2 Specifications & Technical Data (2014-2019)

Technical specs - ARX 36-2 Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.05 t

Transport length: 2.92 m

Transport width: 1.39 m

Transport height: 2.84 m

Travel speed: 10 km/h

Frequency: 41 Hz

Roller width: 1.3 m

Rollers Ø: 0.85 m

Statical line load: 13.8 kg/cm

Centrifugal force: 39.3 kN

Model series: Light Tandem Rollers

More technical details, like: vibration, drive, steering, turning radius outside, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: vibration, drive, steering, turning radius outside, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Ammann ARX 36-2 FAQ

When was the Ammann ARX 36-2 manufactured?

The Ammann ARX 36-2 was manufactured from 2014 to 2019.

How much does the Ammann ARX 36-2 weigh?

The Ammann ARX 36-2 weighs 4.05 tons.

What are the transport dimensions of the Ammann ARX 36-2 tandem vibration roller?

The Ammann ARX 36-2 has a transport length of 2.92 meters, a transport width of 1.39 meters, and a transport height of 2.84 meters.

What is the travel speed of the Ammann ARX 36-2 tandem vibration roller?

The Ammann ARX 36-2 tandem vibration roller has a travel speed of 10 km/h.

What are the compaction parameters of the Ammann ARX 36-2 tandem vibration roller?

The Ammann ARX 36-2 tandem vibration roller operates at a frequency of 41 Hz, generates a centrifugal force of 39.3 kN, and has a statical line load of 13.8 kg/cm.

What are the roller specifications of the Ammann ARX 36-2 tandem vibration roller?

The Ammann ARX 36-2 has rollers that are 1.3 meters wide with a diameter of 0.85 meters.

How much is a Ammann ARX 36-2 Tandem Vibration Roller (2014u20132019) worth?

The residual value of the Ammann ARX 36-2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
