YTO YZD-3 Specifications & Technical Data (2017-2026)

Technical specs - YZD-3 YTO

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3 t

Transport length: 3.5 m

Transport width: 1.39 m

Transport height: 2.2 m

Frequency: 45 Hz

Roller width: 1.2 m

Turning radius outside: 4.6 m

Statical line load: 9.2 kg/cm

Model series: YZD

Engine manuf.: Changchai

Engine type: ZN390Q

Engine power: 22 kW

More technical details, like: vibration, drive, travel speed, rollers Ø, amplitude, turning radius inside, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: vibration, drive, travel speed, rollers Ø, amplitude, turning radius inside, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

YTO YZD-3 FAQ

When was the YTO YZD-3 manufactured?

The YTO YZD-3 was first produced in 2017.

How much does the YTO YZD-3 weigh?

The YTO YZD-3 weighs 3 tons.

What are the transport dimensions of the YTO YZD-3 single-drum roller?

The YTO YZD-3 has transport dimensions of 3.5 meters in length, 1.39 meters in width, and 2.2 meters in height.

What is the turning radius of the YTO YZD-3 single-drum roller?

The YTO YZD-3 has an outside turning radius of 4.6 meters.

What are the frequency and statical line load specifications of the YTO YZD-3 single-drum roller?

The YTO YZD-3 operates at a frequency of 45 Hz and has a statical line load of 9.2 kg/cm.

What is the roller width of the YTO YZD-3 single-drum roller?

The YTO YZD-3 single-drum roller has a roller width of 1.2 meters.

How much is a YTO YZD-3 Single-drum Roller (2017u20132025) worth?

The residual value of the YTO YZD-3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
