XG620H XGMA XG620H Specifications & Technical Data (2017—2026)

Weight: 20t – Transport length: 6.25m – Transport width: 2.33m – Transport height: 3.23m – Travel speed: 10.3km/h – Frequency: 32Hz

XG620H

Years of manufacture: 2017—2026

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - XG620H XGMA

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 20 t

Transport length: 6.25 m

Transport width: 2.33 m

Transport height: 3.23 m

Travel speed: 10.3 km/h

Frequency: 32 Hz

Roller width: 2.13 m

Rollers Ø: 1.55 m

Amplitude: 2.1 mm

Turning radius outside: 6.5 m

Model series: XG

More technical details, like: vibration, drive, turning radius inside, statical line load, centrifugal force, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

XGMA XG620H FAQ

When was the XGMA XG620H manufactured?

The XGMA XG620H was first produced in 2017.

How much does the XGMA XG620H weigh?

The XGMA XG620H weighs 20 tons.

What are the transport dimensions of the XGMA XG620H single-drum roller?

The XGMA XG620H has transport dimensions of 6.25 meters in length, 2.33 meters in width, and 3.23 meters in height.

What is the travel speed of the XGMA XG620H single-drum roller?

The XGMA XG620H has a travel speed of 10.3 km/h.

What is the turning radius of the XGMA XG620H single-drum roller?

The XGMA XG620H has an outside turning radius of 6.5 meters.

What are the compaction performance specifications of the XGMA XG620H?

The XGMA XG620H operates at a vibration frequency of 32 Hz with an amplitude of 2.1 mm.

What are the roller specifications of the XGMA XG620H single-drum roller?

The XGMA XG620H has a roller width of 2.13 meters and a roller diameter of 1.55 meters.

How much is a XGMA XG620H Single-drum Roller (2017u20132025) worth?

The residual value of the XGMA XG620H depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Machine inspection

Ask for inspection of your XGMA XG620H from experts

Mevas is an international operating inspection service for used heavy machinery. Construction machinery inspectors are available in more than 20 countries.

Use this service to minimise the risk when buying used equipment. An inspection by Mevas costs less than repairing a defective hydraulic cylinder.

Enquire machine inspection

Provided by:

Buy & Rent

Compare XGMA XG620H with similar Single-drum Rollers

XGMA XG620H

Weight:: 20 t

Transport length:: 6.25 m

Transport width:: 2.33 m

Transport height:: 3.23 m

XCMG XS202J

Weight:: 20 t

Zoomlion YZ18R

Weight:: 18.2 t

Transport length:: 6.2 m

Transport width:: 2.4 m

Transport height:: 3.2 m

SDLG RS8220

Weight:: 22 t

Transport length:: 6.37 m

Transport width:: 2.36 m

Transport height:: 3.185 m

Lishide RM227

Weight:: 22 t

Transport length:: 6.17 m

Transport width:: 2.43 m

Transport height:: 3.11 m
