YZ18R Zoomlion YZ18R Specifications & Technical Data (2017—2020)

Weight: 18.2t – Transport length: 6.2m – Transport width: 2.4m – Transport height: 3.2m – Vibration: e – Drive: E

Rollers Single-drum Rollers Zoomlion YZ18R
Rollers Single-drum Rollers Zoomlion YZ18R
Rollers Single-drum Rollers Zoomlion YZ18R
Rollers Single-drum Rollers Zoomlion YZ18R

Technical specs - YZ18R Zoomlion

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
18.2 t
Transport length
6.2 m
Transport width
2.4 m
Transport height
3.2 m
Vibration
e
Drive
E
Travel speed
10 km/h
Frequency
35 Hz
Roller width
1.6 m
Rollers Ø
2.15 m
Amplitude
2 mm
Turning radius outside
6.4 m
Model series
YZ
Engine manuf.
Deutz
Engine type
N/A

More technical details, like: turning radius inside, statical line load, centrifugal force, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Sheep foot
No
Oscillation
No
Compression control
No
Aircondition
No

Zoomlion YZ18R FAQ

When was the Zoomlion YZ18R manufactured?

The Zoomlion YZ18R was manufactured from 2017 to 2020.

How much does the Zoomlion YZ18R weigh?

The Zoomlion YZ18R weighs 18.2 tons.

What are the transport dimensions of the Zoomlion YZ18R single-drum roller?

The Zoomlion YZ18R has a transport length of 6.2 meters, a transport width of 2.4 meters, and a transport height of 3.2 meters.

What is the travel speed of the Zoomlion YZ18R single-drum roller?

The Zoomlion YZ18R has a travel speed of 10 km/h.

What type of drive system does the Zoomlion YZ18R have in its undercarriage?

The Zoomlion YZ18R has a simple drive system in its undercarriage.

What is the turning radius of the Zoomlion YZ18R single-drum roller?

The Zoomlion YZ18R has an outside turning radius of 6.4 meters.

What are the compaction capabilities of the Zoomlion YZ18R single-drum roller?

The Zoomlion YZ18R features a single vibration system with a frequency of 35 Hz and an amplitude of 2 mm.

What are the roller specifications of the Zoomlion YZ18R single-drum roller?

The Zoomlion YZ18R has a roller width of 1.6 meters and a roller diameter of 2.15 meters.

How much is a Zoomlion YZ18R Single-drum Roller (2017u20132020) worth?

The residual value of the Zoomlion YZ18R depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
