XG613DH XGMA XG613DH Specifications & Technical Data (2017—2021)
Technical specs - XG613DH XGMA
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 13 t
- Transport length
- 4.9 m
- Transport width
- 2.24 m
- Transport height
- 3.2 m
- Travel speed
- 12 km/h
- Frequency
- 67 Hz
- Roller width
- 2.13 m
- Rollers Ø
- 1.3 m
- Turning radius outside
- 7 m
- Model series
- XG
- Engine manuf.
- Cummins
- Engine type
- QSB4.5-C160-Ⅲ
- Engine power
- 118 kW
More technical details, like: vibration, drive, amplitude, turning radius inside, statical line load, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
XGMA XG613DH FAQ
How much does the XGMA XG613DH weigh?
What are the transport dimensions of the XGMA XG613DH single-drum roller?
What is the travel speed of the XGMA XG613DH single-drum roller?
What is the turning radius of the XGMA XG613DH single-drum roller?
What is the vibration frequency of the XGMA XG613DH's compaction system?
What are the roller specifications of the XGMA XG613DH single-drum roller?
