XS205M XCMG XS205M Specifications & Technical Data (2026—2026)

Weight: 20t – Transport length: 6.99m – Transport width: 2.35m – Transport height: 3.2m – Travel speed: 10.6km/h – Frequency: 28/33Hz

Rollers Single-drum Rollers XCMG XS205M

Visit XCMG live at

Technical specs - XS205M XCMG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
20 t
Transport length
6.99 m
Transport width
2.35 m
Transport height
3.2 m
Travel speed
10.6 km/h
Frequency
28/33 Hz
Roller width
2.13 m
Model series
XS
Engine manuf.
Cummins
Engine type
k.A.
Engine power
142 kW
Revolutions at max torque
2200 rpm
Emission level
EU III

More technical details, like: vibration, drive, rollers Ø, amplitude, turning radius outside, turning radius inside, statical line load, centrifugal force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Sheep foot
No
Oscillation
No
Compression control
No
Aircondition
No
