XS143 XCMG XS143 Specifications & Technical Data (2025—2026)

Weight: 14t – Transport length: 6.2m – Transport width: 2.3m – Transport height: 3.2m – Travel speed: 10.8km/h – Frequency: 30Hz

Rollers Single-drum Rollers XCMG XS143

Visit XCMG live at

Technical specs - XS143 XCMG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
14 t
Transport length
6.2 m
Transport width
2.3 m
Transport height
3.2 m
Travel speed
10.8 km/h
Frequency
30 Hz
Roller width
2.13 m
Model series
XS
Engine manuf.
Cummins
Engine type
k.A.
Engine power
125 kW
Revolutions at max torque
2200 rpm
Emission level
EU II

More technical details, like: vibration, drive, rollers Ø, amplitude, turning radius outside, turning radius inside, statical line load, centrifugal force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Sheep foot
No
Oscillation
No
Compression control
No
Aircondition
No
