XCMG CV123U Specifications & Technical Data (2021-2026)

Technical specs - CV123U XCMG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 12.4 t

Transport length: 6.15 m

Transport width: 2.3 m

Transport height: 3.15 m

Travel speed: 11.2 km/h

Frequency: 35 Hz

Centrifugal force: 280 kN

Engine manuf.: Cummins

Engine type: QSF3.8

Engine power: 97 kW

Revolutions at max torque: 2200 rpm

Emission level: Tier4F

More technical details, like: vibration, drive, roller width, rollers Ø, amplitude, turning radius outside, turning radius inside, statical line load, model series, dimension lxwxh, displacement, max. torque...

More technical details, like: vibration, drive, roller width, rollers Ø, amplitude, turning radius outside, turning radius inside, statical line load, model series, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

XCMG CV123U FAQ

When was the XCMG CV123U manufactured?

The XCMG CV123U was first produced in 2021.

How much does the XCMG CV123U weigh?

The XCMG CV123U weighs 12.4 tons.

What are the transport dimensions of the XCMG CV123U single-drum roller?

The XCMG CV123U has a transport length of 6.15 meters, a transport width of 2.3 meters, and a transport height of 3.15 meters.

What is the travel speed of the XCMG CV123U single-drum roller?

The XCMG CV123U has a travel speed of 11.2 km/h.

What are the frequency and centrifugal force specifications of the XCMG CV123U?

The XCMG CV123U operates at a frequency of 35 Hz and generates a centrifugal force of 280 kN in its compaction system.

How much is a XCMG CV123U Single-drum Roller (2021u20132025) worth?

The residual value of the XCMG CV123U depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
