AW 1080 weycor AW 1080 Specifications & Technical Data (2016—2022)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Visit weycor live at
Technical specs - AW 1080 weycor
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 8 t
- Transport length
- 5.032 m
- Transport width
- 1.7 m
- Transport height
- 2.92 m
- Vibration
- e
- Drive
- A
- Travel speed
- 14 km/h
- Frequency
- 40 Hz
- Roller width
- 1.7 m
- Rollers Ø
- 1.25 m
- Amplitude
- 1.6 mm
- Turning radius outside
- 5.6 m
- Turning radius inside
- 3.9 m
- Statical line load
- 25.88 kg/cm
- Centrifugal force
- 120 kN
- Model series
- AW
- Engine manuf.
- Perkins
- Engine type
- 1104D-44T
- Engine power
- 70 kW
- Displacement
- 4.4 l
- Revolutions at max torque
- 2200 rpm
- Emission level
- Tier 3
More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
weycor AW 1080 FAQ
How much does the weycor AW 1080 weigh?
What are the transport dimensions of the weycor AW 1080 single-drum roller?
What is the travel speed of the weycor AW 1080 single-drum roller?
What type of undercarriage drive does the Weycor AW 1080 have?
What are the turning radius specifications for the weycor AW 1080 single-drum roller?
What are the compaction capabilities of the weycor AW 1080 single-drum roller?
What are the roller specifications of the weycor AW 1080 single-drum roller?
How much is a weycor AW 1080 Single-drum Roller (2016u20132022) worth?
