Sinomach GYS222 Specifications & Technical Data (2023-2026)

Technical specs - GYS222 Sinomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 22 t

Transport length: 6.503 m

Transport width: 2.39 m

Transport height: 3.25 m

Travel speed: 10.3 km/h

Frequency: 32 Hz

Roller width: 2.15 m

Centrifugal force: 390 kN

Model series: GYS

Engine manuf.: Weichai

Engine type: WP6G190E301

Engine power: 140 kW

Displacement: 6.75 l

Revolutions at max torque: 2000 rpm

Max. torque: 820/1500 Nm

No. of cylinders: 6

Emission level: Tier III

More technical details, like: vibration, drive, rollers Ø, amplitude, turning radius outside, turning radius inside, statical line load, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

Sinomach GYS222 FAQ

When was the Sinomach GYS222 manufactured?

The Sinomach GYS222 was first produced in 2023.

How much does the Sinomach GYS222 weigh?

The Sinomach GYS222 weighs 22 tons.

What are the transport dimensions of the Sinomach GYS222 single-drum roller?

The Sinomach GYS222 has a transport length of 6.5 meters, a transport width of 2.39 meters, and a transport height of 3.25 meters.

What is the travel speed of the Sinomach GYS222 single-drum roller?

The Sinomach GYS222 has a travel speed of 10.3 km/h.

What are the compaction capabilities of the Sinomach GYS222?

The Sinomach GYS222 operates at a vibration frequency of 32 Hz and generates a centrifugal force of 390 kN.

What is the roller width of the Sinomach GYS222 single-drum roller?

The Sinomach GYS222 has a roller width of 2.15 meters.
