Shantui SR22MC Specifications & Technical Data (2018-2025)

Technical specs - SR22MC Shantui

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 22 t

Transport length: 6.23 m

Transport width: 2.35 m

Transport height: 3.18 m

Vibration: e

Drive: E

Frequency: 32 Hz

Roller width: 2.14 m

Amplitude: 1.8 mm

Statical line load: 40 kg/cm

Model series: 14-26T

Engine manuf.: Weichai

Engine type: WP6G190E22

Engine power: 140 kW

More technical details, like: travel speed, rollers Ø, turning radius outside, turning radius inside, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

Shantui SR22MC FAQ

When was the Shantui SR22MC manufactured?

The Shantui SR22MC was first produced in 2018.

How much does the Shantui SR22MC weigh?

The Shantui SR22MC weighs 22 tons.

What are the transport dimensions of the Shantui SR22MC single-drum roller?

The Shantui SR22MC has a transport length of 6.23 meters, a transport width of 2.35 meters, and a transport height of 3.18 meters.

What type of drive does the Shantui SR22MC have?

The Shantui SR22MC has a simple drive.

What are the compaction capabilities of the Shantui SR22MC single-drum roller?

The Shantui SR22MC features a single vibration system with a frequency of 32 Hz, an amplitude of 1.8 mm, and a statical line load of 40 kg/cm.

What is the roller width of the Shantui SR22MC single-drum roller?

The roller width of the Shantui SR22MC is 2.14 meters.

How much is a Shantui SR22MC Single-drum Roller (2018u20132025) worth?

The residual value of the Shantui SR22MC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
