SV540D Sakai SV540D Specifications & Technical Data (2018—2026)
Technical specs - SV540D Sakai
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 10.71 t
- Transport length
- 5.84 m
- Transport width
- 2.295 m
- Transport height
- 3.05 m
- Travel speed
- 10 km/h
- Frequency
- 33.3 Hz
- Roller width
- 2.13 m
- Rollers Ø
- 1.53 m
- Amplitude
- 2.09 mm
- Turning radius outside
- 5.6 m
- Centrifugal force
- 255 kN
- Model series
- SV540
- Engine manuf.
- Cummins
- Engine type
- QSB 4,5
- Engine power
- 119 kW
- Displacement
- 4.46 l
- No. of cylinders
- 4
- Emission level
- Tier 4
More technical details, like: vibration, drive, turning radius inside, statical line load, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
Sakai SV540D FAQ
How much does the Sakai SV540D weigh?
What are the transport dimensions of the Sakai SV540D single-drum roller?
What is the travel speed of the Sakai SV540D single-drum roller?
What is the turning radius of the Sakai SV540D single-drum roller?
What are the compaction capabilities of the Sakai SV540D single-drum roller?
What are the roller specifications of the Sakai SV540D single-drum roller?
