Technical specs - 6612 Liugong
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 12 t
- Transport length
- 5.85 m
- Transport width
- 2.29 m
- Transport height
- 2.93 m
- Travel speed
- 12.5 km/h
- Frequency
- 40 Hz
- Roller width
- 2.13 m
- Rollers Ø
- 1.5 m
- Amplitude
- 1.8 mm
- Turning radius outside
- 7.4 m
- Turning radius inside
- 5.27 m
- Statical line load
- 33.55 kg/cm
- Centrifugal force
- 279 kN
- Engine manuf.
- Cummins
- Engine type
- QSB4.5
- Engine power
- 116 kW
- Displacement
- 4.5 l
- Revolutions at max torque
- 2000 rpm
- Max. torque
- 622 Nm
- No. of cylinders
- 4
- Emission level
- Tier 3/EU IIIA
More technical details, like: vibration, drive, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
Yes
Download datasheets (PDF)
Liugong 6612 FAQ
How much does the Liugong 6612 weigh?
What are the transport dimensions of the Liugong 6612 single-drum roller?
What is the travel speed of the Liugong 6612 single-drum roller?
What are the turning radius specifications of the Liugong 6612 single-drum roller?
What are the compaction capabilities of the Liugong 6612 single-drum roller?
What are the roller specifications of the Liugong 6612 single-drum roller?
How much is a Liugong 6612 Single-drum Roller (2014u20132025) worth?
