HMK 110 CS Hidromek HMK 110 CS Specifications & Technical Data (2021—2026)
Visit Hidromek live at
Technical specs - HMK 110 CS Hidromek
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 11.35 t
- Transport length
- 5.85 m
- Transport width
- 2.25 m
- Transport height
- 2.97 m
- Travel speed
- 12 km/h
- Frequency
- 30 Hz
- Roller width
- 2.13 m
- Rollers Ø
- 1.5 m
- Amplitude
- 1.9 mm
- Turning radius inside
- 3.17 m
- Centrifugal force
- 206 kN
- Model series
- HMK
- Engine manuf.
- Deutz
- Engine type
- TCD4.1 L4
- Engine power
- 115 kW
- Displacement
- 4.038 l
- Revolutions at max torque
- 2200 rpm
- Max. torque
- 609/1600 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 101x126 mm
- Emission level
- 3A
More technical details, like: vibration, drive, turning radius outside, statical line load, dimension lxwxh are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
Yes
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
