Hamm HC 70i VIO Specifications & Technical Data (2022-2026)

Technical specs - HC 70i VIO Hamm

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.765 t

Transport length: 4.439 m

Transport width: 2.016 m

Transport height: 2.883 m

Travel speed: 12.5 km/h

Frequency: 36 Hz

Roller width: 1.68 m

Rollers Ø: 1.206 m

Amplitude: 1.38 mm

Turning radius inside: 3.31 m

Statical line load: 23.5 kg/cm

Centrifugal force: 123 kN

Model series: HC

Engine manuf.: Kubota

Engine type: V3307-CR-TE5B

Engine power: 55.4 kW

No. of cylinders: 4

Emission level: EU Stage V / EPA Tier 4

More technical details, like: vibration, drive, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: Yes
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: Yes

Download datasheets (PDF)

Hamm HC 70i VIO FAQ

When was the Hamm HC 70i VIO manufactured?

The Hamm HC 70i VIO was first produced in 2022.

How much does the Hamm HC 70i VIO weigh?

The Hamm HC 70i VIO weighs 6.77 tons.

What are the transport dimensions of the Hamm HC 70i VIO single-drum roller?

The Hamm HC 70i VIO has a transport length of 4.44 meters, a transport width of 2.02 meters, and a transport height of 2.88 meters.

What is the travel speed of the Hamm HC 70i VIO?

The Hamm HC 70i VIO has a travel speed of 12.5 km/h.

What is the inside turning radius of the Hamm HC 70i VIO?

The Hamm HC 70i VIO has an inside turning radius of 3.31 meters.

What are the compaction capabilities of the Hamm HC 70i VIO single-drum roller?

The Hamm HC 70i VIO operates at a frequency of 36 Hz with an amplitude of 1.38 mm, generates a centrifugal force of 123 kN, and has a statical line load of 23.5 kg/cm.

What are the roller specifications of the Hamm HC 70i VIO single-drum roller?

The Hamm HC 70i VIO has a roller width of 1.68 meters and a roller diameter of 1.206 meters.

How much is a Hamm HC 70i VIO Single-drum Roller (2022u20132025) worth?

The residual value of the Hamm HC 70i VIO depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Hamm HC 70i VIO overview

Steering and Brake system

Highlights

Simple, intuitive and language-neutral operation High climbing ability Compact dimensions Compaction system VIO – vibration or oscillation 3-point articulation for outstanding traction and off-road mobility

Roller

Optional Equipment

ROPS cabin with heating and air conditioning, FOPS-approved (level I) Safety belt monitoring device Tachograph Bluetooth interface for Smart Doc Dozer blade Speedometer Automatic engine-off function Camera system Back-up alarm (reversing) Automatic vibration system Working lights Battery isolating switch Tool kit
