Technical specs - HC 160i P Hamm
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 16.28 t
- Transport length
- 6.32 m
- Transport width
- 2.47 m
- Transport height
- 3.05 m
- Travel speed
- 11.9 km/h
- Roller width
- 2.14 m
- Rollers Ø
- 1.677 m
- Amplitude
- 2.15 mm
- Turning radius inside
- 4.131 m
- Statical line load
- 50.16 kg/cm
- Centrifugal force
- 330 kN
- Model series
- HC
- Engine manuf.
- Isuzu
- Engine type
- AQ-6HK1X
- Engine power
- 119.6 kW
- Revolutions at max torque
- 2000 rpm
- No. of cylinders
- 4
- Emission level
- EU Stage V / EPA Tier 4
More technical details, like: vibration, drive, frequency, turning radius outside, dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
Yes
- Sheep foot
-
Yes
- Oscillation
-
Yes
- Compression control
-
No
- Aircondition
-
Yes
