322 P Hamm 322 P Specifications & Technical Data (2020—2022)
Visit Hamm live at
Technical specs - 322 P Hamm
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 22.26 t
- Transport length
- 6.27 m
- Transport width
- 2.49 m
- Transport height
- 3 m
- Vibration
- e
- Drive
- E
- Travel speed
- 14.2 km/h
- Frequency
- 30 Hz
- Roller width
- 2.22 m
- Rollers Ø
- 1.784 m
- Amplitude
- 1.84 mm
- Turning radius inside
- 4.4 m
- Centrifugal force
- 331 kN
- Model series
- 300
- Engine manuf.
- Cummins
- Engine type
- QSB6.7-C220-30
- Engine power
- 164 kW
- No. of cylinders
- 6
- Emission level
- MEP III
More technical details, like: turning radius outside, statical line load, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
Yes
- Oscillation
-
Yes
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
