CA 250 Dynapac CA 250 Specifications & Technical Data (2010—2012)
Visit Dynapac live at
.jpg){kind=logo}
Technical specs - CA 250 Dynapac
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 12.7 t
- Transport length
- 5.5 m
- Transport width
- 2.384 m
- Transport height
- 2.952 m
- Vibration
- e
- Drive
- A
- Travel speed
- 7.5 km/h
- Frequency
- 33 Hz
- Roller width
- 2.13 m
- Rollers Ø
- 1.523 m
- Amplitude
- 1.7 mm
- Turning radius outside
- 5.4 m
- Statical line load
- 25.4 kg/cm
- Model series
- CA
- Engine manuf.
- Cummins
- Engine type
- 4BTA3.9C
- Engine power
- 82 kW
- Displacement
- 3.9 l
- Revolutions at max torque
- 2200 rpm
More technical details, like: turning radius inside, centrifugal force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
Dynapac CA 250 FAQ
How much does the Dynapac CA 250 weigh?
What are the transport dimensions of the Dynapac CA 250 single-drum roller?
What is the travel speed of the Dynapac CA 250?
What type of drive system does the Dynapac CA 250 have in its undercarriage?
What is the turning radius of the Dynapac CA 250 single-drum roller?
What are the compaction capabilities of the Dynapac CA 250 single-drum roller?
What are the roller specifications of the Dynapac CA 250 single-drum roller?
How much is a Dynapac CA 250 Single-drum Roller (2010u20132012) worth?
