Caterpillar CS423E Specifications & Technical Data (2003-2026)

Technical specs - CS423E Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.745 t

Transport length: 4.96 m

Transport width: 1.8 m

Transport height: 2.93 m

Travel speed: 10.5 km/h

Frequency: 30 Hz

Roller width: 1.67 m

Centrifugal force: 143 kN

Model series: CS

Engine manuf.: Caterpillar

Engine type: 3054C

Engine power: 62 kW

Displacement: 4.4 l

Emission level: Tier 4 f

More technical details, like: vibration, drive, rollers Ø, amplitude, turning radius outside, turning radius inside, statical line load, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

Download specalog and datasheets (PDF)

CS423E Caterpillar Specification for Europe (EN)

Caterpillar CS423E FAQ

When was the Caterpillar CS423E manufactured?

The Caterpillar CS423E was first produced in 2003.

How much does the Caterpillar CS423E weigh?

The Caterpillar CS423E weighs 6.75 tons.

What are the transport dimensions of the Caterpillar CS423E single-drum roller?

The Caterpillar CS423E has a transport length of 4.96 meters, a transport width of 1.8 meters, and a transport height of 2.93 meters.

What is the travel speed of the Caterpillar CS423E single-drum roller?

The Caterpillar CS423E has a travel speed of 10.5 km/h.

What are the compaction performance specifications of the Caterpillar CS423E?

The Caterpillar CS423E operates at a frequency of 30 Hz and generates a centrifugal force of 143 kN in its compaction system.

What is the roller width of the Caterpillar CS423E?

The Caterpillar CS423E has a roller width of 1.67 meters.

How much is a Caterpillar CS423E Single-drum Roller (2003u20132025) worth?

The residual value of the Caterpillar CS423E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
