Caterpillar CP12 Specifications & Technical Data (2023-2026)

Technical specs - CP12 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 12.2 t

Travel speed: 11 km/h

Frequency: 30 Hz

Roller width: 2.13 m

Rollers Ø: 1.54 m

Amplitude: 2.1 mm

Turning radius inside: 3.6 m

Statical line load: 30 kg/cm

Centrifugal force: 301 kN

Engine manuf.: Caterpillar

Engine type: C4.4

Engine power: 117 kW

Displacement: 4.4 l

Emission level: EU V

More technical details, like: transport length, transport width, transport height, vibration, drive, turning radius outside, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: Yes
Sheep foot: Yes
Oscillation: No
Compression control: No
Aircondition: Yes

Caterpillar CP12 FAQ

When was the Caterpillar CP12 manufactured?

The Caterpillar CP12 was first produced in 2023.

How much does the Caterpillar CP12 weigh?

The Caterpillar CP12 weighs 12.2 tons.

What is the travel speed of the Caterpillar CP12 single-drum roller?

The Caterpillar CP12 has a travel speed of 11 km/h.

What is the turning radius inside of the Caterpillar CP12 single-drum roller?

The Caterpillar CP12 has an inside turning radius of 3.6 meters.

What are the compaction capabilities of the Caterpillar CP12 single-drum roller?

The Caterpillar CP12 operates at a frequency of 30 Hz with an amplitude of 2.1 mm, generates a centrifugal force of 301 kN, and has a statical line load of 30 kg/cm.

What are the roller specifications of the Caterpillar CP12 single-drum roller?

The Caterpillar CP12 has a roller width of 2.13 meters and a roller diameter of 1.54 meters.

How much is a Caterpillar CP12 Single-drum Roller (2023u20132025) worth?

The residual value of the Caterpillar CP12 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Machine inspection

Ask for inspection of your Caterpillar CP12 from experts

Mevas is an international operating inspection service for used heavy machinery. Construction machinery inspectors are available in more than 20 countries.

Use this service to minimise the risk when buying used equipment. An inspection by Mevas costs less than repairing a defective hydraulic cylinder.

Enquire machine inspection

Provided by:

Buy & Rent

Compare Caterpillar CP12 with similar Single-drum Rollers

Caterpillar CP12

Weight:: 12.2 t

Travel speed:: 11 km/h

Frequency:: 30 Hz

Roller width:: 2.13 m

Caterpillar CS54B

Weight:: 10.55 t

Travel speed:: 11 km/h

Frequency:: 30.5 Hz

Roller width:: 2.13 m

Hamm 2422 DS

Weight:: 11.3 t

JCB VM 116 D

Weight:: 12.5 t

Lonking CDM512D

Weight:: 12 t

Travel speed:: 10.8 km/h

Frequency:: 36 Hz

Roller width:: 2.12 m
