1102D Case 1102D Specifications & Technical Data (1987—2026)
Technical specs - 1102D Case
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 11.1 t
- Transport length
- 5.3 m
- Transport width
- 2.3 m
- Transport height
- 3 m
- Travel speed
- 6 km/h
- Frequency
- 36 Hz
- Roller width
- 2.1 m
- Statical line load
- 82 kg/cm
- Centrifugal force
- 18 kN
- Model series
- D
- Engine manuf.
- Case
- Engine type
- 6590
- Engine power
- 88 kW
- Displacement
- 5.88 l
- Max. torque
- 370 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 102x120 mm
More technical details, like: vibration, drive, rollers Ø, amplitude, turning radius outside, turning radius inside, dimension lxwxh, revolutions at max torque, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
