Bomag BW 220 D-5 Specifications & Technical Data (2021-2026)

Technical specs - BW 220 D-5 Bomag

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 20 t

Transport length: 6.5 m

Transport width: 2.3 m

Transport height: 3.04 m

Vibration: e

Drive: A

Roller width: 2.13 m

Rollers Ø: 1.6 m

Turning radius outside: 4.12 m

Statical line load: 61.8 kg/cm

Model series: BW

Engine manuf.: Deutz

Engine type: TCD2012 L06

Engine power: 150 kW

Revolutions at max torque: 2200 rpm

More technical details, like: travel speed, frequency, amplitude, turning radius inside, centrifugal force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Bomag BW 220 D-5 FAQ

When was the Bomag BW 220 D-5 manufactured?

The Bomag BW 220 D-5 was first produced in 2021.

How much does the Bomag BW 220 D-5 weigh?

The Bomag BW 220 D-5 weighs 20 tons.

What are the transport dimensions of the Bomag BW 220 D-5?

The Bomag BW 220 D-5 has a transport length of 6.5 meters, a transport width of 2.3 meters, and a transport height of 3.04 meters.

What type of drive does the Bomag BW 220 D-5 have in its undercarriage?

The Bomag BW 220 D-5 has an all-wheel drive undercarriage.

What is the outside turning radius of the Bomag BW 220 D-5?

The Bomag BW 220 D-5 has an outside turning radius of 4.12 meters.

What are the compaction capabilities of the Bomag BW 220 D-5?

The Bomag BW 220 D-5 features a single vibration system and has a statical line load of 61.8 kg/cm.

What are the roller specifications of the Bomag BW 220 D-5 single-drum roller?

The Bomag BW 220 D-5 has a roller width of 2.13 meters and a roller diameter of 1.6 meters.

How much is a Bomag BW 220 D-5 Single-drum Roller (2021u20132025) worth?

The residual value of the Bomag BW 220 D-5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
