Bomag BW 219 DH-4 Specifications & Technical Data (2007-2008)

Technical specs - BW 219 DH-4 Bomag

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 19.2 t

Transport length: 6 m

Transport width: 2.3 m

Transport height: 3.02 m

Vibration: e

Drive: A

Travel speed: 13 km/h

Frequency: 30 Hz

Roller width: 2.13 m

Rollers Ø: 1.6 m

Amplitude: 2.14 mm

Statical line load: 60.6 kg/cm

Model series: BW

Engine manuf.: Deutz

Engine type: TCD2012 L06

Engine power: 150 kW

Revolutions at max torque: 2200 rpm

Emission level: T3

More technical details, like: turning radius outside, turning radius inside, centrifugal force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

Bomag BW 219 DH-4 FAQ

When was the Bomag BW 219 DH-4 manufactured?

The Bomag BW 219 DH-4 was manufactured from 2007 to 2008.

How much does the Bomag BW 219 DH-4 weigh?

The Bomag BW 219 DH-4 weighs 19.2 tons.

What are the transport dimensions of the Bomag BW 219 DH-4?

The Bomag BW 219 DH-4 has a transport length of 6 meters, a transport width of 2.3 meters, and a transport height of 3.02 meters.

What is the travel speed of the Bomag BW 219 DH-4?

The Bomag BW 219 DH-4 has a travel speed of 13 km/h.

What type of drive system does the Bomag BW 219 DH-4 use in its undercarriage?

The Bomag BW 219 DH-4 uses an all-wheel drive system in its undercarriage.

What are the compaction parameters of the Bomag BW 219 DH-4 single-drum roller?

The Bomag BW 219 DH-4 features a single vibration system with a frequency of 30 Hz, an amplitude of 2.14 mm, and a statical line load of 60.6 kg/cm.

What are the roller specifications of the Bomag BW 219 DH-4 single-drum roller?

The Bomag BW 219 DH-4 has a roller width of 2.13 meters and a roller diameter of 1.6 meters.

How much is a Bomag BW 219 DH-4 Single-drum Roller (2007u20132008) worth?

The residual value of the Bomag BW 219 DH-4 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
