Technical specs - BW 214 DH-5 Bomag
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 13.9 t
- Transport length
- 6.22 m
- Transport width
- 2.3 m
- Transport height
- 2.99 m
- Vibration
- e
- Drive
- A
- Travel speed
- 10.5 km/h
- Frequency
- 36 Hz
- Roller width
- 2.13 m
- Statical line load
- 40.4 kg/cm
- Centrifugal force
- 285 kN
- Model series
- BW
- Engine manuf.
- Deutz
- Engine type
- TCD 2012 L04 2V
- Engine power
- 103 kW
- Revolutions at max torque
- 2400 rpm
- Cylinder bore x stroke
- 4 mm
- Emission level
- Stage IIIa / TIER3
More technical details, like: rollers Ø, amplitude, turning radius outside, turning radius inside, dimension lxwxh, displacement, max. torque, no. of cylinders are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
Bomag BW 214 DH-5 FAQ
How much does the Bomag BW 214 DH-5 weigh?
What are the transport dimensions of the Bomag BW 214 DH-5?
What is the travel speed of the Bomag BW 214 DH-5?
What type of drive system does the Bomag BW 214 DH-5 use for its undercarriage?
What are the compaction capabilities of the Bomag BW 214 DH-5 single-drum roller?
What is the roller width of the Bomag BW 214 DH-5?
How much is a Bomag BW 214 DH-5 Single-drum Roller (2022u20132025) worth?
