Ammann ARS 200 Specifications & Technical Data (2016-2022)

Technical specs - ARS 200 Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 19.5 t

Transport length: 6.68 m

Transport width: 2.26 m

Transport height: 2.85 m

Vibration: e

Drive: A

Travel speed: 11 km/h

Frequency: 35 Hz

Roller width: 2.13 m

Rollers Ø: 1.6 m

Amplitude: 2 mm

Statical line load: 58.6 kg/cm

Model series: ARS

Engine manuf.: Deutz

Engine type: TCD6.1 L6

Engine power: 160 kW

Emission level: EU V

More technical details, like: turning radius outside, turning radius inside, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: Yes
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

ARS 200 Ammann Specification for Europe (DE)

Ammann ARS 200 FAQ

When was the Ammann ARS 200 manufactured?

The Ammann ARS 200 was manufactured from 2016 to 2022.

How much does the Ammann ARS 200 weigh?

The Ammann ARS 200 weighs 19.5 tons.

What are the transport dimensions of the Ammann ARS 200 single-drum roller?

The Ammann ARS 200 has a transport length of 6.68 meters, a transport width of 2.26 meters, and a transport height of 2.85 meters.

What is the travel speed of the Ammann ARS 200 single-drum roller?

The Ammann ARS 200 has a travel speed of 11 km/h.

What type of drive does the Ammann ARS 200 have in its undercarriage?

The Ammann ARS 200 has an all-wheel drive system in its undercarriage.

What are the compaction capabilities of the Ammann ARS 200 single-drum roller?

The Ammann ARS 200 features a single vibration system with a frequency of 35 Hz, an amplitude of 2 mm, and a statical line load of 58.6 kg/cm.

What are the roller specifications of the Ammann ARS 200 single-drum roller?

The Ammann ARS 200 has a roller width of 2.13 meters and a roller diameter of 1.6 meters.
