Technical specs - ARS 150 Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 18.61 t

Transport length: 5.95 m

Transport width: 2.26 m

Transport height: 2.97 m

Vibration: e

Drive: A

Frequency: 35 Hz

Roller width: 2.13 m

Rollers Ø: 1.5 m

Amplitude: 2.06 mm

Turning radius inside: 3.57 m

Statical line load: 43.4 kg/cm

Model series: ARS

Engine manuf.: Deutz

Engine type: TCD4.1 L4

Engine power: 115 kW

Displacement: 4.038 l

Revolutions at max torque: 2300 rpm

Max. torque: 609/1600 Nm

Emission level: EU V

More technical details, like: travel speed, turning radius outside, centrifugal force, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: Yes
Sheep foot: Yes
Oscillation: No
Compression control: Yes
Aircondition: Yes

Download datasheets (PDF)

Ammann ARS 150 FAQ

When was the Ammann ARS 150 manufactured?

The Ammann ARS 150 was first produced in 2019.

How much does the Ammann ARS 150 weigh?

The Ammann ARS 150 weighs 18.61 tons.

What are the transport dimensions of the Ammann ARS 150 single-drum roller?

The Ammann ARS 150 has a transport length of 5.95 meters, a transport width of 2.26 meters, and a transport height of 2.97 meters.

What type of drive system does the Ammann ARS 150 have in its undercarriage?

The Ammann ARS 150 has an all-wheel drive system in its undercarriage.

What is the inside turning radius of the Ammann ARS 150?

The Ammann ARS 150 has an inside turning radius of 3.57 meters.

What are the compaction capabilities of the Ammann ARS 150 single-drum roller?

The Ammann ARS 150 features a single vibration system with a frequency of 35 Hz, an amplitude of 2.06 mm, and a statical line load of 43.4 kg/cm.

What are the roller specifications of the Ammann ARS 150 single-drum roller?

The Ammann ARS 150 has a roller width of 2.13 meters and a roller diameter of 1.5 meters.
