DV 40 TV Hamm DV 40 TV Specifications & Technical Data (2004—2010)
Visit Hamm live at
Technical specs - DV 40 TV Hamm
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.88 t
- Transport length
- 3.31 m
- Transport width
- 1.425 m
- Transport height
- 2.61 m
- Vibration
- e
- Drive
- A
- Steering
- SL
- Travel speed
- 11 km/h
- Frequency
- 55 Hz
- Roller width
- 1.2 m
- Rollers Ø
- 0.9 m
- Turning radius outside
- 2.24 m
- Statical line load
- 48.5 kg/cm
- Model series
- DV
- Engine manuf.
- Hatz
- Engine type
- 4 W 35 T
- Engine power
- 30 kW
- Revolutions at max torque
- 3000 rpm
More technical details, like: dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Infrared heater
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
