CC2.7GC Caterpillar CC2.7GC Specifications & Technical Data (2021—2026)

Weight: 2.6t – Transport length: 2.58m – Transport width: 1.31m – Transport height: 2.6m – Vibration: d – Drive: E

Rollers Combination Rollers Caterpillar CC2.7GC

CC2.7GC

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - CC2.7GC Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.6 t

Transport length: 2.58 m

Transport width: 1.31 m

Transport height: 2.6 m

Vibration: d

Drive: E

Steering: KL

Travel speed: 8.6 km/h

Frequency: 62 Hz

Roller width: 1.2 m

Statical line load: 13.1 kg/cm

Model series: CC

Engine manuf.: Caterpillar

Engine type: C1.7T

Engine power: 18.4 kW

Displacement: 1.7 l

Emission level: Tier 4i. V

More technical details, like: rollers Ø, turning radius outside, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Infrared heater: No
Oscillation: No
Compression control: No
Aircondition: No

Download specalog and datasheets (PDF)

Caterpillar CC2.7GC FAQ

When was the Caterpillar CC2.7GC manufactured?

The Caterpillar CC2.7GC was first produced in 2021.

How much does the Caterpillar CC2.7GC weigh?

The Caterpillar CC2.7GC weighs 2.6 tons.

What are the transport dimensions of the Caterpillar CC2.7GC?

The Caterpillar CC2.7GC has a transport length of 2.58 meters, a transport width of 1.31 meters, and a transport height of 2.6 meters.

What is the travel speed of the Caterpillar CC2.7GC combination roller?

The Caterpillar CC2.7GC has a travel speed of 8.6 km/h.

What type of drive does the undercarriage of the Caterpillar CC2.7GC have?

The undercarriage of the Caterpillar CC2.7GC has a Simple drive.

What type of steering does the Caterpillar CC2.7GC use for maneuverability?

The Caterpillar CC2.7GC uses articulated-frame steering for maneuverability.

What are the compaction capabilities of the Caterpillar CC2.7GC?

The Caterpillar CC2.7GC features a double vibration system, operates at a frequency of 62 Hz, and has a statical line load of 13.1 kg/cm.

What is the roller width of the Caterpillar CC2.7GC?

The Caterpillar CC2.7GC has a roller width of 1.2 meters.
