CC2.6 Caterpillar CC2.6 Specifications & Technical Data (2018—2018)

Weight: 2.44t – Transport length: 2.575m – Transport width: 1.312m – Transport height: 2.7m – Vibration: d – Drive: E

CC2.6

Years of manufacture: 2018—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - CC2.6 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.44 t

Transport length: 2.575 m

Transport width: 1.312 m

Transport height: 2.7 m

Vibration: d

Drive: E

Steering: KL

Travel speed: 10.5 km/h

Frequency: 63 Hz

Roller width: 1.2 m

Rollers Ø: 0.72 m

Turning radius outside: 2.475 m

Statical line load: 10.2 kg/cm

Model series: CC

Engine manuf.: Caterpillar

Engine type: C1.5

Engine power: 27 kW

Displacement: 1.5 l

Emission level: Tier 4 f

More technical details, like: dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Infrared heater: No
Oscillation: No
Compression control: No
Aircondition: No

Download specalog and datasheets (PDF)

Caterpillar CC2.6 FAQ

When was the Caterpillar CC2.6 manufactured?

The Caterpillar CC2.6 was manufactured in 2018.

How much does the Caterpillar CC2.6 weigh?

The Caterpillar CC2.6 weighs 2.44 tons.

What are the transport dimensions of the Caterpillar CC2.6?

The Caterpillar CC2.6 has a transport length of 2.58 meters, a transport width of 1.31 meters, and a transport height of 2.7 meters.

What is the travel speed of the Caterpillar CC2.6?

The Caterpillar CC2.6 has a travel speed of 10.5 km/h.

What type of drive system does the undercarriage of the Caterpillar CC2.6 have?

The undercarriage of the Caterpillar CC2.6 has a simple drive system.

What are the turning radius and steering type of the Caterpillar CC2.6?

The Caterpillar CC2.6 has an outside turning radius of 2.475 meters and features articulated-frame steering.

What are the compaction capabilities of the Caterpillar CC2.6 combination roller?

The Caterpillar CC2.6 features a double vibration system, operates at a frequency of 63 Hz, and has a statical line load of 10.2 kg/cm.

What are the roller specifications of the Caterpillar CC2.6?

The Caterpillar CC2.6 has rollers that are 1.2 meters wide with a diameter of 0.72 meters.
