BW 151 AC-4 AM Bomag BW 151 AC-4 AM Specifications & Technical Data (2005—2014)
Visit Bomag live at
Technical specs - BW 151 AC-4 AM Bomag
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 8.8 t
- Transport length
- 4.61 m
- Transport width
- 1.84 m
- Transport height
- 3 m
- Vibration
- e
- Drive
- A
- Steering
- KL
- Travel speed
- 9.7 km/h
- Frequency
- 45 Hz
- Roller width
- 1.68 m
- Model series
- BW
- Engine manuf.
- Deutz
- Engine type
- BF4M2011
- Engine power
- 60 kW
- Displacement
- 3.11 l
More technical details, like: rollers Ø, turning radius outside, statical line load, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Infrared heater
-
No
- Oscillation
-
No
- Compression control
-
Yes
- Aircondition
-
No
Download datasheets (PDF)
Bomag BW 151 AC-4 AM FAQ
How much does the Bomag BW 151 AC-4 AM weigh?
What are the transport dimensions of the Bomag BW 151 AC-4 AM?
What is the travel speed of the Bomag BW 151 AC-4 AM?
What type of drive system does the Bomag BW 151 AC-4 AM have in its undercarriage?
What type of steering does the Bomag BW 151 AC-4 AM use for maneuverability?
What are the compaction capabilities of the Bomag BW 151 AC-4 AM?
What is the roller width of the Bomag BW 151 AC-4 AM?
How much is a Bomag BW 151 AC-4 AM Combination Roller (2005u20132014) worth?
