BW 120 SLC-5 Bomag BW 120 SLC-5 Specifications & Technical Data (2021—2026)
.png)
.png)
Visit Bomag live at
Technical specs - BW 120 SLC-5 Bomag
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.25 t
- Transport length
- 2.529 m
- Transport width
- 1.272 m
- Transport height
- 2.562 m
- Drive
- A
- Steering
- KL
- Travel speed
- 10 km/h
- Frequency
- 72 Hz
- Roller width
- 1.2 m
- Rollers Ø
- 0.7 m
- Statical line load
- 9.6 kg/cm
- Model series
- BW
- Engine manuf.
- Kubota
- Engine type
- D1703
- Engine power
- 18.5 kW
- No. of cylinders
- 3
- Emission level
- Stage V / TIER4f
More technical details, like: vibration, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
Yes
- Infrared heater
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
