BW 100 AC-4 Bomag BW 100 AC-4 Specifications & Technical Data (2008—2012)
Visit Bomag live at
Technical specs - BW 100 AC-4 Bomag
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.3 t
- Transport length
- 2.475 m
- Transport width
- 1.076 m
- Transport height
- 2.475 m
- Vibration
- e
- Drive
- A
- Steering
- KL
- Frequency
- 70 Hz
- Roller width
- 1 m
- Model series
- BW
- Engine manuf.
- Kubota
- Engine type
- D1703M-E
- Engine power
- 24.7 kW
- Revolutions at max torque
- 2600 rpm
- Emission level
- III B
More technical details, like: travel speed, rollers Ø, turning radius outside, statical line load, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Infrared heater
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
Bomag BW 100 AC-4 FAQ
How much does the Bomag BW 100 AC-4 weigh?
What are the transport dimensions of the Bomag BW 100 AC-4?
What type of undercarriage drive does the Bomag BW 100 AC-4 have?
What type of steering does the Bomag BW 100 AC-4 use for maneuverability?
What is the vibration system of the Bomag BW 100 AC-4?
What is the roller width of the Bomag BW 100 AC-4?
How much is a Bomag BW 100 AC-4 Combination Roller (2008u20132012) worth?
