ARX 26 K Ammann ARX 26 K Specifications & Technical Data (2013—2021)

Weight: 2.25t – Transport length: 2.33m – Transport width: 1.24m – Transport height: 2.55m – Vibration: e – Drive: A

Rollers Combination Rollers Ammann ARX 26 K

ARX 26 K

Years of manufacture: 2013—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - ARX 26 K Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.25 t

Transport length: 2.33 m

Transport width: 1.24 m

Transport height: 2.55 m

Vibration: e

Drive: A

Steering: KL

Travel speed: 10 km/h

Frequency: 66 Hz

Roller width: 1.2 m

Rollers Ø: 0.7 m

Turning radius outside: 2.25 m

Statical line load: 10.3 kg/cm

Model series: Light Tandem Rollers

Engine manuf.: Yanmar

Engine type: 4TNV88

Engine power: 19 kW

Displacement: 1.6 l

Revolutions at max torque: 2200 rpm

Emission level: Tier 3 a

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Infrared heater: No
Oscillation: No
Compression control: Yes
Aircondition: No

Download datasheets (PDF)

Ammann ARX 26 K FAQ

When was the Ammann ARX 26 K manufactured?

The Ammann ARX 26 K was manufactured from 2013 to 2021.

How much does the Ammann ARX 26 K weigh?

The Ammann ARX 26 K weighs 2.25 tons.

What are the transport dimensions of the Ammann ARX 26 K?

The Ammann ARX 26 K has a transport length of 2.33 meters, a transport width of 1.24 meters, and a transport height of 2.55 meters.

What is the travel speed of the Ammann ARX 26 K?

The Ammann ARX 26 K has a travel speed of 10 km/h.

What type of drive system does the Ammann ARX 26 K have in its undercarriage?

The Ammann ARX 26 K features an all-wheel drive system in its undercarriage.

What are the maneuverability specifications of the Ammann ARX 26 K?

The Ammann ARX 26 K has an outside turning radius of 2.25 meters and features articulated-frame steering.

What are the compaction capabilities of the Ammann ARX 26 K?

The Ammann ARX 26 K features a single vibration system operating at a frequency of 66 Hz and has a statical line load of 10.3 kg/cm.

What are the roller specifications of the Ammann ARX 26 K?

The Ammann ARX 26 K has rollers that are 1.2 meters wide with a diameter of 0.7 meters.
