DP 605 Perlini DP 605 Specifications & Technical Data (2004—2016)

Weight: 38.9t – Standard tyres: 21.00x35 – Dump capacity: 26.2m³ – Net load: 53t – Steering: VL – Transport length: 9.5m

DP 605

Years of manufacture: 2004—2016

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - DP 605 Perlini

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 38.9 t

Standard tyres: 21.00x35

Dump capacity: 26.2 m³

Net load: 53 t

Steering: VL

Transport length: 9.5 m

Transport width: 4.3 m

Transport height: 4 m

Travel speed: 57 km/h

Turning radius outside: 10 m

Loading height: 3.6 m

Engine manuf.: Detroit

Engine type: MTU 12 V 2000 TA

Engine power: 567 kW

Displacement: 23.89 l

Revolutions at max torque: 2100 rpm

More technical details, like: model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, engine manufacturer, aspiration, engine output - gross, transmission type, drive configuration, final drive, tyre size, retarder - type, length - overall, height - max, height - over canopy / rock guard rail, ground clearance, width - over tyres, width - transport, width - operating, wheelbase, length - body, loading height, full dump height, width - over body, hoist - angle, fuel tank, engine oil, cooling system, transmission - system, body type, struck capacity, heaped capacity, gears - forward / reverse, speed - forward maximum, net weight, payload, gross weight, payload - highest possible are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Central lubrication: Yes
Heated dump body: Yes
Tailgate: No
Aircondition: Yes

Download datasheets (PDF)

Perlini DP 605 FAQ

When was the Perlini DP 605 manufactured?

The Perlini DP 605 was manufactured from 2004 to 2016.

How much does the Perlini DP 605 rigid dump truck weigh?

The Perlini DP 605 rigid dump truck weighs 38.9 tons.

What are the transport dimensions of the Perlini DP 605 rigid dump truck?

The Perlini DP 605 has a transport length of 9.5 meters, a transport width of 4.3 meters, and a transport height of 4 meters.

What is the travel speed of the Perlini DP 605 rigid dump truck?

The Perlini DP 605 has a travel speed of 57 km/h.

What are the standard tyres of the Perlini DP 605?

The Perlini DP 605 is equipped with standard tyres sized 21.00x35.

What are the maneuverability specifications of the Perlini DP 605 rigid dump truck?

The Perlini DP 605 has a front steering system and an outside turning radius of 10 meters.

What is the material handling capacity of the Perlini DP 605 rigid dump truck?

The Perlini DP 605 has a net load capacity of 53 tons and a dump capacity of 26.2 cubic meters.

How much is a Perlini DP 605 Rigid dump truck (2004u20132016) worth?

The residual value of the Perlini DP 605 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
