DP 255 Perlini DP 255 Specifications & Technical Data (1995—2016)

Weight: 17.8t – Standard tyres: 16.00x25 – Dump capacity: 13.5m³ – Net load: 30t – Steering: VL – Transport length: 7.31m

DP 255

Years of manufacture: 1995—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - DP 255 Perlini

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 17.8 t

Standard tyres: 16.00x25

Dump capacity: 13.5 m³

Net load: 30 t

Steering: VL

Transport length: 7.31 m

Travel speed: 58 km/h

Turning radius outside: 8.1 m

Loading height: 2.95 m

Engine manuf.: Detroit

Engine type: S60

Engine power: 298 kW

Displacement: 14 l

Revolutions at max torque: 2100 rpm

More technical details, like: transport width, transport height, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, passenger seat, air conditioner, telematics available, engine manufacturer, engine model, aspiration, cooling, engine output - gross, transmission type, drive configuration, final drive, speeds - forward, tyre size, retarder - type, length - overall, height - over canopy / rock guard rail, ground clearance, width - over tyres, width - transport, width - operating, wheelbase, length - body, loading height, width - over body, fuel tank, engine oil, cooling system, transmission - system, body type, struck capacity, heaped capacity, gears - forward / reverse, speed - forward maximum, net weight, payload, gross weight, payload - highest possible are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Central lubrication: Yes
Heated dump body: Yes
Tailgate: No
Aircondition: Yes

Download datasheets (PDF)

Perlini DP 255 FAQ

When was the Perlini DP 255 manufactured?

The Perlini DP 255 was manufactured from 1995 to 2016.

How much does the Perlini DP 255 weigh?

The Perlini DP 255 weighs 17.8 tons.

What is the transport length of the Perlini DP 255 rigid dump truck?

The transport length of the Perlini DP 255 is 7.31 meters.

What is the travel speed of the Perlini DP 255 rigid dump truck?

The Perlini DP 255 has a travel speed of 58 km/h.

What are the undercarriage specifications of the Perlini DP 255 rigid dump truck?

The Perlini DP 255 is equipped with standard tyres sized 16.00x25.

What are the maneuverability specifications of the Perlini DP 255 rigid dump truck?

The Perlini DP 255 has a front steering system and an outside turning radius of 8.1 meters.

What is the material handling capacity of the Perlini DP 255 rigid dump truck?

The Perlini DP 255 has a net load capacity of 30 tons and a dump capacity of 13.5 cubic meters.
