DR50C Liugong DR50C Specifications & Technical Data (2024—2026)

Weight: 36.8t – Standard tyres: 21.00-35/36PR(E4) – Dump capacity: 21.8m³ – Net load: 45t – Transport length: 8.972m – Transport width: 4.492m

Rigid Dump Trucks Liugong DR50C

Visit Liugong live at

Technical specs - DR50C Liugong

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
36.8 t
Standard tyres
21.00-35/36PR(E4)
Dump capacity
21.8 m³
Net load
45 t
Transport length
8.972 m
Transport width
4.492 m
Transport height
4.31 m
Travel speed
55 km/h
Loading height
3.52 m
Model series
C
Engine manuf.
Cummins
Engine type
QSX15
Engine power
388 kW
Displacement
15 l
Revolutions at max torque
1400 rpm
Max. torque
2365 Nm
No. of cylinders
6
Emission level
Tier 3/Stage III

More technical details, like: steering, turning radius outside, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter
No
Central lubrication
No
Heated dump body
No
Tailgate
No
Aircondition
No
